Lightweight Fireproof Waterproof PVC Gypsum Ceiling Panel for Suspended Ceiling Systems

Marca:	SUNHOUSE
Número do modelo:	TH0005
MOQ:	100
preço:	$0.90-1.60

Informações detalhadas

Descrição do produto

Informações detalhadas

Lugar de origem:

Cantão, China

Garantia:

1 ano

Serviço pós-venda:

Suporte laboral em linha, inspeção no local, peças sobresselentes livres

Capacidade de solução do projeto:

design gráfico, design de modelos 3D, solução total para projetos

Aplicativo:

Teto do hotel, do Oiffer e decoração de Interion/hotel

estilo de design:

Moderno

Função:

À prova de fogo, isolação térmica, umidade - prova, Molde-prova, Fumo-prova, som - absorção, à prova

Recurso:

Tetos artísticos, tetos do favo de mel, tetos integrados, tetos perfurados

Forma de telha de teto:

Retângulo

Tipo de ladrilho de teto:

Tecidos de PVC

Tamanho:

595x595mm, 600x600mm, 603x603mm, 605x605mm

Grossura:

7mm, 7.8mm, 8mm, 9mm…

Borda:

Borda quadrada com fita ou sem fita

Densidade:

280~350 kg/m3

Matérias-primas:

Placa de gesso

Superfície:

Filme importado ou doméstico do PVC

Certificado:

ISSO/CE disponível

Quantidade mínima:

1*20GP

Amostra grátis:

Disponível a qualquer hora

peso:

Leve

Material:

PVC e gesso

Palavra-chave:

Teto da gipsita do PVC

Palavra-chave:

Placa do teto do Pvc

Essencial:

Placa de gesso

Cor:

Branco (personalizável)

Tipo de montagem:

Deixe cair dentro

Método de instalação:

sistema do teto suspendido

Resistência à água:

Impermeável

Descrição do produto

PVC Laminated Gypsum Ceiling Panels – 595×595 mm Suspended Ceiling Tiles

PVC laminated gypsum ceiling panels are composite building materials consisting of a gypsum core with a factory-applied PVC film surface layer. They are designed for use in exposed grid suspended ceiling systems, providing a balance of dimensional stability, surface durability, and functional performance in controlled indoor environments.

Technical Specifications

Parameter	Specification
Standard Dimensions	595 × 595 mm, 600 × 600 mm, 603 × 603 mm, 605 × 605 mm
Thickness Range	7.0 mm, 7.8 mm, 8.0 mm, 9.0 mm
Edge Type	Square edge (with or without reinforcing tape)
Core Density	280 – 350 kg/m³
Core Material	Gypsum board with stabilizing additives
Surface Finish	PVC film lamination (matte, satin or embossed texture available)
Performance Characteristics	Moisture resistance, wipe-clean surface, moderate fire retardancy, basic sound absorption (perforated options)
Surface Patterns	Plain, perforated, sand texture, geometric, simulated wood grain
Grid System Compatibility	Standard 15 mm or 24 mm exposed T-bar grid
Primary Applications	Commercial offices, hotels, hospitals, schools, retail premises and light industrial interiors

Installation and Handling Guidelines

Technical Notes for Proper Use:

• Panels must be stored flat on a level surface in a dry, ventilated warehouse with relative humidity below 85%. Maximum safe stacking height is 8–10 panels.
• Allow panels to acclimatize to the installation environment for at least 24 hours prior to fixing.
• Installation temperature range: 5°C to 40°C. Avoid installation in areas with sustained humidity exceeding 90%.
• When cutting, use a fine-tooth hand saw or scoring knife. Appropriate personal protective equipment (dust mask, safety glasses) is recommended to control gypsum dust.
• The supporting T-bar grid must be installed level and rigidly fixed according to manufacturer load requirements.
• Surface cleaning should be performed with a soft damp cloth and neutral detergent. Avoid abrasive materials or solvent-based cleaners that may degrade the PVC layer.
• Perforated panels should be inspected periodically for dust accumulation in the holes to maintain designed acoustic performance.

Project References

Selected Project Supply Records:

• 26,000 m² of 8 mm perforated PVC laminated panels supplied for a Grade-A office tower in Southeast Asia. The system provided effective sound absorption in open-plan office areas while maintaining ease of access for maintenance.

• 14,500 m² of 7.8 mm plain-finish panels used in a mid-range hotel renovation project. The moisture-resistant surface performed reliably in bathroom corridors and high-humidity zones.

• 11,000 m² of 9 mm sand-texture panels installed in a regional hospital outpatient building, meeting requirements for cleanability and low dust emission in clinical environments.

Frequently Asked Questions

Q1. What are the recommended storage conditions?

A: Panels should be kept flat on level supports in a dry warehouse. Avoid direct sunlight, rain exposure, or stacking higher than 10 panels to prevent warping.

Q2. What payment and trade terms do you offer?

A: Standard payment is 30% T/T deposit with balance prior to shipment, or irrevocable L/C at sight. Trade terms include FOB, CFR and CIF.

Q3. What is the normal production lead time?

A: For standard specifications and colors, production lead time is typically 20–25 days after receipt of deposit. Custom surface patterns may require additional time.

Q4. Do you accept OEM or custom design orders?

A: Yes. We can produce according to client-specified dimensions, surface patterns, or colors, subject to minimum order quantity requirements.

Q5. Are product samples available?

A: Samples of standard items can be provided free of charge. The recipient is responsible for courier shipping costs.
